Post4T: Crank-Angle or Degree Based Output.

Selecting to display "Thermo- and Gasdynamic Traces" from the main menu opens the following dialog box:

The top left lists the 8 types of trace files that can be selected:

  1. Pressure Traces - this allows the pressure to be recorded in any pipe, duct, port, plenum, cylinder and box
  2. Mach Indexes - this traces the value of the mach index in any port or pipe and past any valve
  3. Temperature Traces - this allows the temperature to be recorded in any pipe, duct, port, plenum, cylinder and box
  4. Wave Traces - this allows the left and right moving waves to be independently displayed in any duct, pipe or port
  5. Purity Traces - this displays the purity of the gas in any port, duct, pipe or cylinder
  6. Combustion Traces - this displays the combustion characteristics, depending on the combustion model chosen
  7. Mass Flow Traces - this displays the mass flow past any valve, through any position in a pipe or port and through the turbocharger compressor, turbine and wastegate
  8. Turbocharger Traces - this displays the various turbocharger results



The following graphs are just a small example of the outputs that are available.

1. Pressure Traces

The following is a sample of pressure traces. It shows the inlet port, cylinder (limited to 3bar) and exhaust port pressures for cylinder 4 of a 1000cc Mini engine with port event lines, valve lift profiles and the maximum piston speed line included:

2. Mach Traces

This figure shows the mach traces for the exhaust port of cylinder 4 of the 1000cc Mini engine. The three traces show the mach values through the valve opening (ExVMach), the smallest cross section of the port (ExPMach) and about a 100mm (user defined position) from the valve head (ExMach). It shows that the flow past the valve is sonic for an extended period of time.

3. Temperature Traces

The in cylinder temperatures are shown. The black line shows the mean temperature inside the cylinder (CylTemp), the red line the temperature of the unburnt mixture (TUnBurnt), and the green line shows the burnt mixture temperature (TBurnt). It is also possible to display the temperature in any point of any plenum or duct.

4. Wave Traces

This shows the left and right moving waves at the exhaust valve, which explains why they are the same when the valve is closed. Note how the blowdown pulse (PepRight) differs from the reflected pulse (PepLeft) during the valve open period.

5. Purity Traces

The purity of cylinder 3 and 4 of the Mini 1000 with the siamesed inlet ports are plotted with both referenced to each cylinder's TDC. This shows that at inlet valve closing (IVC) the purity in the cylinders are the same, meaning the performance difference between the two cylinders are not the result of one scavenging better than the other.

6. Combustion Traces

The traces shown here are the mass of unburnt gas, the mass of enflamed mixture and the mass of burnt mixture during turbulent combustion.

7. Mass Flow Traces

This shows the mass flow in the inlet ports of cylinder 3 and 4 of the Mini 1000cc engine. This engine has siamesed inlet ports with the ports of cylinder 1 and 2 and cylinder 3 and 4 siamesed. It shows clearly how the suction of cylinder 4 is beginning to reverse the flow in cylinder 3 inlet port during its closing period.

To compare the mass flow of the two ports they are plotted over each other. By comparing the two curves one can see how port 3 influences the flow in port 4 and later how port 4 influences the flow in port 3.

8. Turbocharger Traces

This shows the pressure ratios across the the compressor and the turbine and waste gate.
